Brother MFC-8480DN Service Manual

5-7
Confidential
CIS
model
ADF chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
ADF FG harness Taptite cup S M3x6 SR 1 0.7±0.1 (7±1)
ADF relay PCB ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
Motor frame ASSY
Taptite cup S M3x6 SR 3 0.7±0.05 (7±0.5)
Taptite cup S M3x10 1 0.7±0.05 (7±0.5)
Pickup solenoid ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
ADF motor
Screw pan (S/P
washer) M3x6 DB
2 0.7±0.1 (7±1)
Exit solenoid ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
Lower document chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
Separate roller holder ASSY Taptite cup B M3x10 1 0.8±0.1 (8±1)
Support plate Taptite cup B M3x6 3 0.5±0.1 (5±1)
Document exit tray sensor
cover ASSY
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Document exit tray roller holder
ASSY
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Upper document sub chute Taptite cup B M3x10 2 0.5±0.1 (5±1)
Gear 34 Taptite cup B M3x10 1 0.5±0.1 (5±1)
Exit chute Taptite bind B M4x10 1 0.7±0.05 (7±0.5)
CCD
model
Document scanner unit Taptite cup B M4x20 2 0.8±0.1 (8±1)
Scanner top cover ASSY Taptite cup B M4x12 6 0.8±0.1 (8±1)
Lock lever B Taptite B M3x6 1 0.4±0.05 (4±0.5)
Lock lever A Taptite B M3x6 2 0.4±0.05 (4±0.5)
FB FG harness Taptite cup S M3x6 1 0.8±0.1 (8±1)
Drive plate ASSY Taptite B M3x8 4 0.5±0.1 (5±1)
Scanner motor FB
Screw, pan (S/P
washer) M3X6
2 0.7±0.1 (7±1)
Pulley ASSY Taptite B M3x6 2 0.4±0.05 (4±0.5)
CIS
model
FB FG harness Taptite cup S M3x6 1 0.8±0.1 (8±1)
CCD
model
Panel unit ASSY Taptite cup B M4x12 4 0.7±0.1 (7±1)
Panel bottom cover Taptite cup B M3x10 4 0.5±0.1 (5±1)
NCU FG harness ASSY
Screw, pan (S/P
washer) M3.5X6 SR
1 0.4±0.05 (4±0.5)
NCU shield plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
NCU shield cover
Screw, pan (S/P
washer) M3.5X6
1 0.4±0.05 (4±0.5)
NCU PCB ASSY Taptite cup S M3x6 2 0.5±0.05 (5±0.5)
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
