Brother MFC-8480DN Service Manual

5-9
Confidential
CCD
model
CIS
model
Main PCB
Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
Screw pan M3x6 2 0.5±0.1 (5±1)
Gear plate calking ASSY
Taptite bind B M4x12 8 0.9±0.05 (9±0.5)
Taptite cup S M3x6 SR 1 0.7±0.1 (7±1)
Main motor ASSY Taptite cup S M3x6 4 0.7±0.1 (7±1)
Plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
Main shield plate ASSY
Taptite bind B M4x12 3 0.9±0.1 (9±1)
Taptite cup S M3x6 1 0.7±0.1 (7±1)
MP solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Spring Taptite cup B M3x8 1 0.4±0.1 (4±1)
T1 solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Register solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Ejector solenoid Taptite bind B M3x10 1 0.5±0.1 (5±1)
New toner actuator Taptite cup B M2x6 1
0.13±0.03
(1.3±0.3)
Laser scanner unit Taptite cup S M3x6 5 0.7±0.1 (7±1)
LVPS PCB unit terminal
Screw, pan (S/P
washer) M3.5X6 SR
1 0.5±0.05 (5±0.5)
Base plate LV Taptite bind B M4x12 5 0.8±0.1 (8±1)
NCU FG harness
Screw, pan (S/P
washer) M3.5X6 SR
1 0.5±0.05 (5±0.5)
LV insulation sheet Taptite bind B M4x12 1 0.8±0.1 (8±1)
SW holder ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
Safety louver Taptite bind B M3x10 1 0.5±0.1 (5±1)
Base plate HV Taptite bind B M4x12 4 0.8±0.1 (8±1)
HV insulation sheet Taptite bind B M4x12 1 0.8±0.1 (8±1)
High-voltage PS PCB ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
Toner LED PCB unit ASSY Taptite pan B M3x8 1 0.5±0.1 (5±1)
Frame L Taptite bind B M4x12 4 0.8±0.1 (8±1)
(Under bar) Taptite bind B M4x12 2 0.7±0.1 (7±1)
MP feed frame Taptite bind B M3x8 2 0.5±0.1 (5±1)
MP PE sensor ASSY Taptite bind B M3x8 1 0.5±0.1 (5±1)
Feed frame Taptite bind B M4x12 2 0.7±0.1 (7±1)
PE EG sensor ASSY Taptite bind B M3x8 1 0.5±0.1 (5±1)
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)
