Brother MFC-8480DN - Page 270

5-17
Confidential
2 PE EG sensor ASSY
3 Front Cover Sensor ASSY
PE EG sensor ASSY
Paper feed frame
Hook "B"
Hole "A"
PE EG sensor ASSY
Paper Feed frame
High-voltage PS PCB ASSY
Hook "A"
Hole "A"
Machine top side
(Machine body upside down)
Hook "B"
Front cover sensor ASSY
Relay front PCB ASSY
Hooks
Frame L
Pin
Hook
Pin
