Brother MFC-8480DN Service Manual

App. 1-12
Confidential
• Selectors 1 through 3: [Redial/Pause] button setting and 2nd dial tone detection
• Selectors 4 through 6: Detection of 2nd dial tone
Upon detection of the 2nd dial tone for the time length specified by these selectors, the
machine starts dialing.
This setting is effective only when the 2nd dial tone detection function is activated by
selectors 1 through 3 (Setting 101, 110, or 111).
This function does not apply in those countries where no dial tone detection function is
supported.
• Selector 7: No. of 2nd dial tone detection cycles
This selector sets the number of dial tone detection cycles required for starting dialing.
• Selector 8: Allowable instantaneous interrupt during reception of 2nd dial tone
This selector sets the allowable instantaneous interrupt period that should be ignored
during reception of the 2nd dial tone.
Selectors
1 2 3
0 0 0 No wait is inserted even if the [Redial/Pause] button is pressed.
0 0 1
0 1 0
0 1 1
1 0 0
If you press the [Redial/Pause] button during dialing, the machine will
insert wait as defined in the above table.
If the [Redial/Pause] button is pressed repeatedly, the machine inserts
the specified wait multiplied by the number of depressions. It applies
also in hook-up dialing.
1 0 1
1 1 0
1 1 1
When these selectors are set to "1, 0, 1":
Each time you press the [Redial/Pause] button in dialing, the machine
will wait for the 2nd dial tone to be sent via the communications line
regardless of pulse dialing or tone dialing.
When these selectors are set to "1, 1, 0":
If you press the [Redial/Pause] button in pulse dialing, the machine will
first wait for the 2nd dial tone to be sent via the communications line.
After that, pressing the [Redial/Pause] button will cause the machine to
insert a WAIT of 3.5 seconds. In tone dialing, the machine will insert a
WAIT of 3.5 seconds.
When these selectors are set to "1, 1, 1":
If you press the [Redial/Pause] button, the machine will first wait for the
2nd dial tone to be sent via the communications line regardless of pulse
dialing or tone dialing. After that, pressing the [Redial/Pause] button will
cause the machine to insert a wait of 3.5 seconds.
((In those countries where no dial tone detection function is supported,
setting these selectors to "1, 0, 1," "1, 1, 0," or "1, 1, 1" inserts a wait of
3.5 seconds.)

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
