Brother MFC-8480DN Service Manual

App. 1-40
Confidential
<WSW40> (V.34 modem settings)
• Selectors 3 through 8: Masking of symbol rate(s)
These selectors allow you to limit the transmission speed range in V.34 mode by masking
the desired symbol rate(s). Transmission speeds assigned to the symbol rates are listed on
the next page. The setting made by these selectors will limit the setting made by selectors
1 through 4 on WSW39.
If selector 3 is set to "1" to mask the 3429 symbols/second when the first transmission
speed choice is 33600 bps (specified by selectors 1 through 4 of WSW39), for example,
then the allowable maximum transmission speed will be limited to 31200 bps. If selector 8
is set to "1" to mask the 2400 symbols/second when the first transmission speed choice is
33600 bps, then the allowable maximum transmission speed remains 33600 bps.
If selector 8 is set to "1" to mask the 2400 symbols/second when the first transmission
speed choice is 21600 bps (specified by selectors 1 through 4 on WSW39), then the
allowable maximum transmission speed remains 21600 bps but the minimum transmission
speed will be limited to 4800 bps.
Selector No. Function Setting and Specifications
1
2
Not used.
3
I
8
Masking of symbol rate(s)
Not masking Masking
No. 3 0 1
3429 symbols/sec
No. 4 0 1 3200 symbols/sec
No. 5 0 1 3000 symbols/sec
No. 6 0 1 2800 symbols/sec
No. 7 - - Not used.
No. 8 0 1
2400 symbols/sec
Note:
• WSW40 takes effect only when the V.34 mode is permitted (WSW19, selector 7) in
models supporting V.34 mode.

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
