Brother MFC-8480DN Service Manual

App. 1-47
Confidential
<WSW47> (Switching between high- and full-speed USB)
• Selectors 3 and 4: Delay of FAX line disconnection when switching to the pseudo-
ringing external telephone
When the machine receives a phone call, it can make the connected external telephone
ring (so called pseudo-ringing). During pseudo-ringing, if you pick up the handset of the
external telephone, the line might be disconnected due to cut-off of the line current. To hold
the line, the machine may supply line current by making use of the pulse generator circuit
that forms a parallel loop. This way the FAX line disconnection may be delayed. These
selectors determine the delay period.
Selector No. Function Setting and Specifications
1
Handling paper at the
occurrence of a paper feed
timing error (Not used.)
2
Reducing to B4 from A4 and
sending at the real time sending
0: No 1: Yes
3
4
Delay of FAX line disconnection
when switching to the pseudo-
ringing external telephone
No. 3 4
0 0: 200 ms
0 1: 400 ms
1 0: 700 ms
1 1: 1000 ms
5
Disable the ringer of external
telephone at non-ring reception
0: No 1: Yes
6 Not used.
7
Disable the ringer of external
telephone with CAR signal when
caller ID service is available
0: No 1: Yes
8
Switching between high-speed
USB and full-speed USB
0: Auto switching between high-speed
USB (ver. 2.0) and full-speed USB
(ver. 1.1)
1: Fixed to full-speed USB (ver. 1.1)
Note:
• Selector 1 is applicable only to models equipped with flat-bed scanners.
• Selectors 3 and 4 are applicable only to models supporting pseudo-ringing of a
connected external telephone.

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
