Brother MFC-8480DN Service Manual

App. 1-64
Confidential
<WSW76> (The limited number of the documents in reverse for paper ejection
of the simplex scanning from ADF)
• Selectors 1 through 8:The limited number of the documents in reverse for paper ejection
of the simplex scanning from ADF
These selectors are used to set the limited number of the paper ejection under the
following condition.
- The machine takes action simplex scanning from the ADF.
- The documents which are stacked on the ADF are ejected in reverse of the documents
which has been scanned.
There is a possibility that loading problem or dog-ear problem occurs if the limited number
is over a maximum number which machine can paper feeding.
<WSW77> (The limited number of the documents in reverse for paper ejection
of the duplex scanning from ADF)
• Selectors 1 through 8:The limited number of the documents for paper ejection of the
duplex scanning from ADF
These selectors are used to set the limited number of the paper ejection when the machine
takes action duplex scanning from the ADF.
There is a possibility that loading problem or dog-ear problem occurs if the limited number
is over a maximum number which machine can paper feeding.
Selector No. Function Setting and Specifications
1
I
8
The limited number of the
documents in reverse for paper
ejection of the simplex scanning
from ADF
No.12345678
00000000:0
00000001:1
00000010:2
00000011:3
00000100:4
|
01100011:99
01100100 or later: Invalidity
Selector No. Function Setting and Specifications
1
I
8
The limited number of the
documents in reverse for paper
ejection of the duplex scanning
from ADF
No.12345678
00000000:0
00000001:1
00000010:2
00000011:3
00000100:4
|
01100011:99
01100100 or later: Invalidity

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
