Brother MFC-8480DN Service Manual

App. 6-1
Confidential
GLOSSARY
 ACRONYMS AND TECHNICAL TERMS
In this Service Manual, the manual specific acronyms and technical terms are used in
addition to the generally used ones. The table below contains typical acronyms and technical
terms that are used throughout this manuals.
APIPA Automatic Private IP Addressing
ASIC Application Specific Integrated Circuit
ASSY Assembly
CN Connector
CPU Central Processing Unit
dB decibel
DEV Development
DIMM Dual Inline Memory Module
dpi dots per inch
DX Duplex
EEPROM Electronically Erasable and Programmable Read Only Memory
FR Feed Roller
FU Fuser
HEX Hexadecimal
HUM Humidity
HV High Voltage
HVPS High Voltage Power Supply
IEEE 1284 Institute of Electrical and Electronic Engineers 1284
IF Interface
IPv4 Internet Protocol Version 4
IPv6 Internet Protocol Version 6
LCD Liquid Crystal Display
LD Laser Diode
LED Light Emitting Diode
LT Lower Tray
LV Low Voltage
LVPS Low Voltage Power Supply
MP Multi-Purpose
N/A Not Applicable
NC* Network Circuit
PF Paper Feed
PP gear Pressure Plate gear
ppm Pages per minute
PU Pick-Up roller
RAM Random Access Memory
REGI Registration
SB Switch Back

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
