Brother MFC-8480DN Service Manual

3-7
Confidential
Not Registered You tried to access a One
Touch or Speed Dial
number that is not
programmed.
Set up the One Touch or Speed Dial
number.
3-74
Out of Memory The machine’s memory is
full.
Fax sending or copy operation in
progress
Do one of the following:
Press Start to send or copy the
scanned pages.
Press Stop/Exit and wait until the
other operations in progress finish,
and then try again.
Clear the data from the memory.
Print operation in process
Do one of the following:
Reduce print resolution.
Clear the faxes from the memory.
3-35
Print Unable XX The machine has a
mechanical problem.
Perform processing with the error
code.
3-12
3-13
3-18
3-19
3-20
3-21
3-37
3-38
3-39
Protected Device The protect switch of the
USB Flash memory drive
is on.
Turn off the protect switch of the USB
Flash memory drive. 3-36
Rename the File There is already a file on
the USB Flash memory
drive with the same name
as the file you are trying to
save.
Change the file name of the file on
the USB Flash memory drive or the
file you are trying to save.
-
Replace Parts
Drum or
Replace Drum
The drum unit is the end of
its life.
Replace the drum unit.
3-14
The drum unit counter was
not reset when a new drum
was installed.
1) Open the front cover, and then
press Clear/Back.
2) Press 1 to reset.
Replace Parts
Fuser Unit or
Replace Fuser
It is time to replace the
fuser unit.
Replace the fuser unit.
3-15
Replace Parts
Laser Unit or
Replace Laser
It is time to replace the
laser unit.
Replace the laser unit.
3-15
Replace Parts
PF Kit MP or
Replace PF Kit
MP
It is time to replace the
paper feeding kit for the
MP tray.
Replace the PF Kit MP.
3-14
Replace Parts
PF Kit 1 or
Replace PF Kit 1
It is time to replace the
paper feeding kit for Tray
1.
Replace the PF Kit 1.
3-15
Error Message Type of Error Action
Refer
to

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
