Brother ULT-2002D - Free Arm; Supplemental Spool Pin; Top Cover

Setting Up 1-5
1 —
2 —
3 —
4 —
5 —
6 —
7 —
8 —
?
!
9 —
CONTENTS
Index
■ Top Cover
Open the top cover to wind the bobbin or do the upper
threading. To open the cover, place your hand under the
clear section of the cover and lift up.
■ Supplemental Spool Pin
Use this spool pin to wind the bobbin thread during sew-
ing, or when sewing with the twin needle (see pages 1-29,
2-5).
■ Flat Bed Attachment
Use the free arm sewing option to attach cuffs, hem pant
legs, and sew other tubular pieces. Pull the flat bed at-
tachment to the left to remove it and create the conven-
ient free arm sewing mode.
