■ Winding the Bobbin During Sewing
With this machine, you can wind the bobbin during sewing. It will be convenient to wind the
bobbin embroidery thread while sewing embroidery. The threading process is different from the
earlier section, so read and follow the instructions carefully.
1 Supplemental spool pin
1. Align the groove in the bobbin with the spring on the
bobbin winder shaft, and set the bobbin on the shaft.
1 Groove of the bobbin
2 Spring on the shaft
2. Pull up the supplemental spool pin and set it in the
“up” position.
1 Supplemental spool pin
3. Place the spool of thread on the supplemental spool
pin, so that thread unrolls from the back. Then push a
spool cap onto the spool pin as far as possible to se-
cure the thread spool.
1 Spool pin
2 Spool cap
3 Thread spool
