Section04FUELSYSTEM
Subsection 02 (CARBURETORS, THROTTLE AND CHOKE CABLES)
While choke lever is fully open, pull choke cable
until cam lever reaches the stopper. Tighten cable
housing adjusting and locking nuts in this position.
As a confirmation, the gap between the stopper
andthecamlevershouldbewithin0and0.5mm
(0 and 1/64 in).
A
A32C32A
A. Within0and0.5mm(0and1/64in)
192 mmr2005-077
