Section 06 ENGINE MANAGEMENT (SDI)
Subsection 03 (COMPONENT INSPECTION, REPLACEMENT AND ADJUSTMENT)
COMPONENT INSPECTION,
REPLACEMENT AND ADJUSTMENT
SERVICE TOOLS
Description Part Number Page
Fluke 111.............................................................................. 529 035 868 .........................................251
hose pinchers ......................................................................
295 000 076 .........................................254
pressure gauge.....................................................................
529 035 591 .........................................258
VCK (Vehicle Communication Kit).........................................
529 035 981
.................................249, 259
wrench.................................................................................. 529 035 899 ................................. 259–260
SERVICE PRODUCTS
Description Part Number Page
anti-seize lubricant................................................................ 293 800 070
......................................... 272
dielectric grease ...................................................................
293 550 004 .........................................261
Loctite 5910.......................................................................... 293 800 081
.................................269, 272
pulley flange cleaner.............................................................
413 711 809 .........................................255
GENERAL
Engine problems are not necessarily related to the
engine management system.
It is important to ensure that the mechanical in-
tegrity of the engine and drive system are present:
– good transmission system operation
– good engine compression and properly operat-
ing mechanical components, no leaks etc.
– fuel pump connection and fuel lines without
leaks.
Check the chart in TROUBLESHOOTING section
to have an overview of problems and suggested
solutions.
When replacing a component, always check its
operation after installation.
FUEL SYSTEM
WARNING
The fuel system of a fuel injection system
holds much more pressure than that of a car-
bureted snowmobile. Prior to disconnecting
a hose or to removing a component from
the fuel system, follow the recommenda-
tion described here. Pay attention that some
hoses may have more than one clamp at their
ends. Ensure to reinstall the same quantity
of clamps at assembly.
– UsetheVCK(VehicleCommunicationKit)
(P/N 529 035 981) to release the fuel pressure
in the system. Look in the Activation section
of the software B.U.D.S. (ensure to use the
latest version available on BOSSWeb).
mmr2005-081 249
