BRP SUMMIT - Hydraulic Brake

Section 08 DRIVE SYSTEM
Subsection 05 (BRAKE)
HYDRAULIC BRAKE
A33D1PS
5
1
12
13
14
9
6
16
17
15
25 Nm
(18 lbfft)
10
20
42 Nm
(31 lbfft)
21
19
8
7
24 Nm
(18 lbfft)
18
4
3
11
Antiseize
lubricant
X models
14 Nm
(124 lbfin)
18 Nm
(13 lbfft)
24 Nm
(18 lbfft)
8 Nm
(71 lbfin)
2
1 Nm
(9 lbfin)
6 Nm
(53 lbfin)
10
Antiseize
lubricant
354 mmr2005-090
