Section 13 WIRING DIAGRAM
Subsection 01 (WIRING DIAGRAMS)
AREA LOCATION
1
Right hand side of engine
2 Engine
3 Near right hand side footrest
4
Near driven pulley
5
Under console
6 Under hood
7
Near fuel tank
8 Under engine
9
Nearsteeringcolumnoronprimary
air intake silencer
10
On handlebar
11
Injection oil tank
12
Secondary air intake silencer
HOUSING REFERENCE PER AREA
The next two letters of the connector identifica-
tion number represents a connector reference. If
there are many connectors in the same area this
helps identify which wire is in which connector.
- M C
D
XX/XX
A00I04I
1
MC
WIRE LOCATION IN CONNECTOR
HOUSING
The third portion of the connector identification
number represents the location of the wire in the
connector housing. This could be identified by ei-
ther a number such as 1, 2, 3 or by a letter such as
A, B, C depending on the type of connector used.
XX/XX
A00I04H
D
D
1- MC
486 mmr2005-102
