Section12TECHNICALDATA
Subsection 02 (LIQUID COOLED MODELS)
GSX/GTX/MX Z GSX/GTX/MX Z/SUMMIT
MODEL
500 SS 600 HO 800 HO
ELECTRICAL
Battery 12 V, 18 A•h (if applicable)
Headlamp W 60/55 (H4)
Taillight and stoplight W 8/27
Tachometer and speedometer bulbs W 2x3
Fuel and temperature gauge bulbs W —
Starter solenoid A 30 (if applicable)
Fuse
Fuel level sensor A —
FUEL SYSTEM
GSX/GTX/MX Z TM40 – B313 TM40 – B316 TM40–B319
SUMMIT — TM40 – B325 TM40 – B328Carburetor type
793 HO Power TEK (GSX/GTX/MX Z) N.A. N.A. TM40–B322
GSX/GTX/MX Z/SUMMIT 360 380 400
Main jet
793 HO Power TEK (GSX/GTX/MX Z) N.A. N.A. 440
Needle jet P-0M
Pilot jet 17.5
GSX/GTX/MX Z 9DGM15–58 9DHI14–58 9DGI16–58
SUMMIT — 9DGK11–58 9EGY2–58Needle identification
793 HO Power TEK (GSX/GTX/MX Z) N.A. N.A. 9EGI04–58
GSX/GTX/MX Z 1
SUMMIT — 3Clip position
793 HO Power TEK (GSX/GTX/MX Z) N.A. N.A. —
Slide cut-away 2.0
Float adjustment mm (in) —
Air or pilot screw adjustment ± 1/16 turn 1.5
Idle speed ± 200 RPM 1600 1500
GSX/GTX/MX Z Unleaded
Gas type
SUMMIT — Unleaded Premium unleaded
Inside North America (R+M)/2 87 or higher (SUMMIT 800 HO: 91)
Pump octane number
Outside North America RON 91 or higher (SUMMIT 800 HO: 95)
Gas/oil ratio Injection
Injection oil XP-S mineral injection oil
COOLING SYSTEM
Type Liquid
Ethyl glycol/water mix (50% coolant, 50% distilled water).
Mixture
Use coolant specifically designed for aluminum engines.Coolant
Premix P/N 219 700 362 — 12x1L
Thermostat opening temperature °C(°F) 42 (108)
Radiator cap opening pressure kPa (PSI) 90 (13)
472 mmr2005-101
