Section12TECHNICALDATA
Subsection 02 (LIQUID COOLED MODELS)
GSX/GTX/MX Z GSX/GTX/MX Z/SUMMIT
MODEL
500 SS 600 HO 800 HO
CAPACITIES
Fuel tank L (U.S. gal) 40 (10.6)
Chaincase/gearbox mL (U.S. oz) 250 (8.5)
GSX 4.9 L (165.7 U.S. oz)
GTX 5.17 L (174.8 U.S. oz)
Adrenaline 4.9 L (165.7 U.S. oz)
Ren./Ren. X — 5.17 L (174.8 U.S. oz)MX Z
Trail 4.9 L (165.7 U.S. oz) —
144 in — 4.59 L (152.2 U.S. oz)
SUMMIT (Adrenaline)
151 in — — 4.9 L (165.7 U.S. oz)
144 in — — 4.59 L (152.2 U.S. oz)
151 in — — 4.9 L (165.7 U.S. oz)
Cooling system
SUMMIT (X)
159 in — — 4.69 L (158.6 U.S. oz)
Injection oil reservoir 3.5 L (118 U.S. oz)
TIGHTENING TORQUE (engine cold)
Drive pulley retaining screw (5)
Exhaust manifold nuts or bolts 22 N•m(16lbf•ft)
Magneto ring nut 125 N•m(92lbf•ft)
M6 9N•m(80lbf•in)
Crankcase nuts or screws
M8 29 N•m(21lbf•ft)
Crankcase/engine support nuts or screws 35 N•m(26lbf•ft)
Cylinder head screws 29 N•m(21lbf•ft)
Crankcase/cylinder nuts or screws 40 N•m(30lbf•ft)
Axial fan shaft nut N.A.
478 mmr2005-101
