Section 12 TECHNICAL DATA
Subsection 03 (LIQUID COOLED (SDI) MODELS)
GSX/GTX/MX Z
MODEL
600 HO SDI
CAPACITIES
Fuel tank L(U.S.gal) 40 (10.6)
Chaincase/gearbox mL (U.S. oz) 250 (8.5)
GSX 4.9 L (165.7 U.S. oz)
GTX 5.17 L (174.8 U.S. oz)
Adrenaline/X 4.9 L (165.7 U.S. oz)
Cooling system
MX Z
Renegade/Renegade X 5.17 L (174.8 U.S. oz)
Injection oil reservoir 3.5 L (118 U.S. oz)
TIGHTENING TORQUE (engine cold)
Drive pulley retaining screw (5)
Exhaust manifold nuts or bolts 22 N•m(16lbf•ft)
Magneto ring nut 125 N•m(92lbf•ft)
M6 9N•m(80lbf•in)
Crankcase nuts or screws
M8 29 N•m(21lbf•ft)
Crankcase/engine support nuts or screws 35 N•m(26lbf•ft)
Cylinder head screws 29 N•m(21lbf•ft)
Crankcase/cylinder nuts or screws 40 N•m(30lbf•ft)
Axial fan shaft nut N.A.
