4-22 Taking Measurements and Analyzing Data
IMPORTANT! After you click a second analysis (not a filter), the Analysis toolbox goes
blank because you can perform only one analysis per branch. If you want to perform more
than one analysis, click the Profile Filter branch and then add another analysis, which then
becomes an additional branch of the Data Analyzer.
Setting the Parameters for an Analysis or Filter
To set the default parameters for an analysis or filter, right-click its icon, click Default Settings,
make your settings in the window that appears, and then click OK. The settings will now be applied
during every future operation of this type.
Selecting the Meta Data
To select the types of meta data to be stored with each dataset, click the Meta Data button in
the Data Analyzer.
To view the meta data that is already associated with an active dataset, click the Meta Data button on
the toolbar above the Data Analyzer.
CREATING A VISION RECIPE
A Vision recipe contains all of the information that the system needs to make a single scan
measurement. It also includes the Analyzer recipe that is active when you create and save the Vision
recipe, so you can scan a sample and then visualize and analyze the resulting dataset with a single
click.
To create and save a Vision recipe:
1 Select a scan type and make measurement selections in the Measurement Setup window.
2 Do one of the following:
• To save this Vision recipe independently of the currently active Analyzer recipe, click Save > Vision
Recipe on any Ribbon Tab.
• To save the currently active Analyzer recipe as part of this Vision recipe, select the Default Analyzer
check box on the Data Analyzer Toolbar and then click Save > Vision Recipe on any Ribbon Tab.
3 In the Save As window, enter a recipe name. The system supplies the file extension.
4 To save your settings as the default Vision recipe that the system will apply to every new scan
measurement, select the Set as the Startup Recipe check box on top of the Data Analyzer.
5 Click Save.
