4 LUBRICATION CHART
No
PART
Lubricant
Type of
Lubrication
Daily
250 Miles
(Inclusive)
General
FRAME GROUP
3
Front fork (top)
CG-1 (AL)
1 nipple
Grease Gun
2
Front fork (centre)
CG-1 (AL)
1 nipple
Grease Gun
4
Steering Stem (top)
CG-1 (AL)
1 nipple
Grease Gun
5
Steering Stem (bottom)
CG-1 (AL)
2 nipple
Grease Gun
7
Steering Head (top)
CG-1 (AL)
1 nipple
Grease Gun
6 Steering Head (bottom) CG-1 (AL) 1 nipple Grease Gun
8
Saddle nose pivot
CG-1 (AL)
1 nipple
Grease Gun
11
Front wheel hub
CG-1 (AL)
Re pack
-
Re pack w shops every 5000 miles
12 Rear wheel hub CG-1 (AL) Re pack - Re pack w shops every 5000 miles
BRAKE GROUP
9 Brake pedal CG-1 (AL) 1 nipple Grease Gun
16
Brake cam (front)
CG-1 (AL)
1 nipple
Grease Gun
15
Brake cam (rear)
CG-1 (AL)
1 nipple
Grease Gun
Bowden control wire
OE-30
Oil Can
Few Drops
Foot brake linkage
OE-30
Oil Can
Few Drops
ENGINE GROUP
1
Engine oil tank
OE50
5 pints
Replenish
Replenish
Drain & refill at 1000 miles (AO17)
19
Primary chain case
OE50
Reservoir
Replenish
Replenish
Drain & refill at 1000 miles (AO17)
1/20 Oil Filters OE50 Wash in petrol every 2000 miles
IGNITION GROUP
Advance Retard Cable etc
OE30
Oil Can
Few drops
Contact breaker tappet
OE30
Oil Can
One drop
22
Contact breaker cam
CG-1 (AL)
Hand smear
Slight smear
Generator (drive end)
WB-2
Re pack
Re pack w shops
21 Generator (commutator end) OE30 Oil Can Few drops
FUEL GROUP
Air cleaner
N/A
Carburetter control cables
OE30
Oil Can
Few drops
Throttle handle bar grip
OE30
Oil Can
Few drops
TRANSMISSION GROUP
10
Speedometer drive
CG-1 (AL)
1 nipple
Grease Gun
Speedometer cable
OE30
Oil can
Few drops
14 Gear box GO-90 1 pint Replenish Drain & refill each 6000 miles No 18
12
Clutch push rod
OE-50
Oil can
Few drops
Clutch bowden control wire
OE30
Oil can
Few drops
Clutch handle bar grip
OE30
Oil can
Few drops
Rear chain
OE30
Oil can
Few drops
Wash in paraffin and soak in oil OE-
50 every 2000 miles. Workshops
5
