4.2.11.4 LIMIT SETUP screen
Figure 4-24: LIMIT SETUP Menu
The limit setup screen is not a menu but only serves to inform the user of the hardware
capabilities of the AC source. The cursor can be moved to any of the fields in this screen but
these fields can be changed. The following informationone of n is provided on this screen:
Entry Description
VOLTAGE Maximum AC rms or DC voltage available in the high voltage
e
FREQ LO
PHASE C
s a single phase model, this field will
will
range.
CUR LIMIT Maximum AC rms current limit available in the low voltag
range.
Lowest possible fundamental frequency that can be
programmed.
FREQ HI Highest possible fundamental frequency that can be
programmed.
Phase angle of phase C with respect to phase A in three phase
mode. If the AC source i
shown 0°. If the AC source is a split phase model, this field
shown 180°.
MX Series 113
