California Instruments MX30-1 - Figure 2-4: MX30-3 Voltage; Current Rating Chart for 200;400 V DC Ranges; Figure 2-5: MX45-3 Voltage; Current Rating Chart for 200;400 V DC Ranges - Max. Rating

User Manual – Rev AJ California Instruments
Figure 2-4: MX30-3 Voltage / Current Rating Chart for 200/400 V DC Ranges
Figure 2-5: MX45-3 Voltage / Current Rating Chart for 200/400 V DC Ranges – Max. Rating
Current
(DC)
Voltage (DC)
100 400
50
30
40
20
10
25 A
200
Low V Range
High V Range
50 A
20
40
18 MX Series
