4.5 Standard Measurements
Standard measurements are always available through the MEAS key on the front panel. These
measurements are spread across two to four screens to enhance readability. Switching betw
these screens can be done by successively pressing the MEAS button on the front panel. Thi
will cause the screen to cycle through all available measure
een
s
ment screens.
ments 4.5.1 Standard Controller Measure
For MX Series power sources with the –1 or –3 standard controllers, the following two
measurement screens are available:
Mode AC DC
MEASUREMENTS 1
VOLTAGE AC rms voltage DC Voltage
CURRENT AC rms current DC Current
FREQUENCY Frequency n/a
POWER Real power power
MEASUREMENTS 2
VA power POWER Apparent power
PEAK CURR Highest AC current
found
Highest DC current
found
PO Power factor n/a WER FACT
CREST FACT Crest factor n/a
126 MX Series
