8. Top Assembly Replaceable Parts
Note that different generation MX units may use different sub assemblies. Check the serial tag on the
back of the MX to determine the applicable top assembly number to determine the correct sub assembly
or part required. For amplifiers, refer to the amplifier serial tag for the relevant amplifier top assembly
part num ber.
Ref. CI P/N Description Vendor
Qty
Location
Top Assembly 7003-427 / 7003-422
A2 el Assy. Prog.
Osc.
California Instruments 1 7003-421-1 Front Pan
7003-718-2 CPU board assy. All 3 phase
MX.
California Instruments 1
7003-718-4 CPU board assy. MX30-1,
MX45-1 only.
California Instruments 1
7000-723-4 Keyboard/Display assy. California Instruments 1
Top Assembly 7003-400
A2 7003-401-1 Front Panel Assy. Prog.
Osc.
California Instruments 1
5100-707-2 CPU / Phase A board assy. California Instruments 1
7000-722-2 Phase B/C board assy. California Instruments 1
7000-723-1 Keyboard/Display assy. California Instruments 1
Top Assembly 7003-427
A1 7003-721-1 PC Assy. RS232 / GPIB /
USB
California Instruments 1
A1 7003-721-2 PC Assy. RS232 / GPIB /
USB / LAN
California Instruments 1
A6 7003-722-1 PC Assy., Low Volt PSU California Instruments 1
Top Assembly 7003-422 / 7003-400
A1 7003-703-1 PC Assy. RS232 / GPIB California Instruments 1
A1 7003-703-2 PC Assy. RS232 / GPIB California Instruments 1
A6 7003-702-1 PC Assy., Low Volt PSU California Instruments 1
Top Assembly 7003-427 / 7003-422 / 7003-400
A2 7003-408-1 Front Panel Assy., Auxiliary California Instruments 1
A3 7003-715-1 PC Assy., System Interface California Instruments 1
A4 7003-701-1 PC Assy., V / I Sense California Instruments 1
A14 7003-713-1 PC Assy., PWR Interconnect California Instruments 1
A10 7003-714-1 PC Assy., EMI Filter California Instruments 1
A7 7003-418-1 Amplifier Assy., 15kVA California Instruments 1
A8 7003-418-1 Amplifier Assy., 15kVA California Instruments 1
A9 7003-418-1 Amplifier Assy., 15kVA California Instruments 1
B1 241186 Fan, 3", 24VDC NMB Technology
3110KLO5WB50-P00
1
CB1 270224 Circuit Breaker, 2.5A, 300V AIRPAX
IELH111-1-61-2-50-D-01-V
1
K1 245235 Relay, 3C, 30A, 24VDC Deltrol Controls
21014 - 82
1
K8 245235 Relay, 3C, 30A, 24VDC Deltrol Controls
21014 - 82
1
K2 245236 Relay, 3C, 90A, 24VDC EE Controls
EECLS47.22NTW
1
