User Manual – Rev AJ California Instruments
Current
(RMS)
Voltage (RMS)
75 300
100
60
80
40
20
50 A
150
Low V Range
High V Range
100 A
7.5
15
Figure 2-2: MX45-3 Voltage / Current Rating Chart for 150/300 V AC Ranges – Max Rating.
Figure 2-3: Voltage / Current Rating Chart for 150/300 V AC Ranges – Derated.
MX Series 17
