User Manual – Rev AJ California Instruments
MODE
Top View
from back of MX
Interface Board
Detail
view
DIP S1
S1
MASTER
AUX
SINGLE-CAB
MULTI-CAB
1 2 3 4
chassis
Figure 3-18: Multi-Cabinet DIP Switch Location and Setting
64 MX Series
