3.7.3 BNC Connectors
BNC connectors. Functions are called out on rear panel decal. Table shows connections from
left to right when standing at the rear of the MX cabinet.
Table 3-6: BNC Connectors
BNC Description
1 Trigger Input (TTL input)
2 Trigger Output (T
may n
TL output) (Same signal connection as Function Strobe. Some units
ot have this output connec ou don’t get an output trigger on this BNC, use the
tion Strobe BNC instead.)
ted. If y
Func
3 Function Strobe (TTL output) (Sa onnection as Trigger Output) me signal c
4 Clock (TTL output on Master / TT input on Auxiliary) L
5 Lock (TTL output on Master / TT on Auxiliary) L input
6 Emergency Shut off inter connec d only on –MB systems with –ES Option. t. Installe
Table 3-7: BNC Connectors
3.7.4 External Sense Connector
Pin Description
1 Phase A sense
2 Phase B sense
3 Phase C sense
4 Neutral sense
Table 3-8: External Sense Connector
