User Manual – Rev AJ California Instruments
4.2.13 MEASUREMENT CAL FACTORS Menu
Figure 4-27: MEASUREMENT CAL FACTORS Menu (Series I only)
: MEASUREMENT CAL FACTORS Menu (Series II only)
provides access to the measurement calibration
calibration password has been entered. Refer to the calibration section in this manual for details
Description
Figure 4-28
The MEASUREMENT CAL FACTORS menu
parameters. The parameters apply to the selected mode of operation (AC or DC mode). For
three phase configurations, the PHASE keys toggle between the three calibration screens for
each phase. These parameters are password protected and can only be changed after the
on performing a calibration.
Note that Series II MX models only have two measurement calibration factors. Series I models
require additional cal factors as shown. The following calibration factors are available from this
menu:
Entry
actor. (Series I
only)
ement
mperature compensated zero offset voltage measurement
I
nt
VOLT FS Full scale voltage measurement calibration factor.
VOLT 0 Zero offset voltage measurement calibration f
VOLT FS HT Temperature compensated full-scale voltage measur
calibration factor. (Series I only)
VOLT 0 HT Te
calibration factor. (Series I only)
CURR FS Full scale current measurement calibration factor.
CURR 0 Zero offset current measurement calibration factor. (Series
only)
CURR FS HT Temperature compensated full-scale current measurement
calibration factor. (Series I only)
CURR 0 HT Temperature compensated zero offset current measureme
calibration factor. (Series I only)
MX Series 117
