Note: Output specifications apply below the Current / Voltage rating lines shown in the
V/I rating chart below.
Figure 2-7: MX30-3 Voltage / Current Rating Chart, -HV Option
Current
(RMS)
Voltage (RMS)
100 200 300 400
37.5
37.5 A
-HV Range
20
Figure ting. 2-8: MX45-3 Voltage / Current Rating Chart, -HV Option – Max. Ra
Figure 2-9: Voltage / Current Rating Chart, -HV Option – Derated.
