User Manual - Rev AJ California Instruments
6.4.7 Option -413 Calibration
If the IEC61000-4-13 auxiliary generator option is installed, the following calibration procedure
applies. Refer to for the locations of the adjustment pots on the Aux. Waveform Generator (CI
CAU tion when
P/N 7004-719-1).
TION: This will require the top cover to be removed. Always use cau
removing the top panel to not touch the LV supply. This procedure should
be performed by qualified personnel only
1. Select AC mode, 300V range, 0.0 Vac, 50 Hz. Do not apply a load. Close output relay.
2. Select
INTER HARMONICS the MENU 2 screen. The following values will be displayed:
INTER HARMONICS
REF. VOLT = 0.0 VAC FREQUENCY = 400 Hz
VOLTAGE = 0.0% REF. COUPL = OFF
REFERENCE = OFF
3. e
4. Sele
5. Sele
6. e
Vac
Sel ct REFERENCE and program ON with the shuttle.
ct
REF VOLT and program 230.0.
ct
VOLTAGE and program 8.7%.
Sel ct
FREQUENCY and program 400 Hz. This combination of values should generate a 20.0
RMS output from the
AUX. Generator. See sample below:
INTER HARMONICS
REF. VOLT = 230.0 VAC FREQUENCY = 400 Hz
VOLTAGE = 8.7%
REF. COUPL = OFF
REFERENCE =
ON
7. Adju
exte
st the respective pot for the output phase being calibrated for a 20.0 ± 1.0 volt output on the
rnal
AC DVM.
PHASE ADJUSTMENT POT
A R9
B R10
C R11
8. Select in the INTER HARMONIC screen and program the frequency to 1800 Hz.
9. Select the
OUTPUT CALIBRATION screen.
10. Select the
INTER HARM FS value.
11. Use the shuttle to calibrate the output voltage to 20.00 ± 1.0 volts rms.
12. Select
REFERENCE and program OFF with the shuttle.
13. Open output relay. This completes the -413 option calibration.
FREQUENCY
MX Series
168
