User Manual – Rev AJ California Instruments
The following top-level menu choices can be accessed from the MENU key:
Description Entry
MENU 1
PROGRAM The PROGRAM menu allows output parameters the be
changed.
MEASURE The MEASUREMENTS screens are not menus in that no user
entries are required.
TRANSIEN The TRANSIENTS menu allows output transients to be
programmed.
The WAVEFORMS menu allows different waveforms to be
selected from the waveform library.
MORE The MORE selection causes the second part of the MENU
screen to be displayed. (MENU 2)
MENU 2
ADVANCED The ADVANCED MEAS. screens are for display only. No user
entries are required.
APPLICATI The APPLICATIONS menu provides access to the optional
firmware application programs that may be installed in the MX
Series AC source.
SETUP REGISTERS The SETUP REGISTERS menu allows complete instrument
settings and transient list programs to be saved to nonvolatile
memory.
MORE The MORE selection causes the third part of the MENU screen
to be displayed. (MENU 3)
MENU 3
UTILITY The UTILITY menu provides o less nly us
s screens those PIB a 2C (
applies to USB and LAN) interface settings, initial startup
values, etc.
OUTPUT IMPEDANCE The OUTPUT IMPEDANCE m l of the
source output impedance. X30-3Pi or M
only)
MEASUREMENT CAL The MEASUREMENT CAL menu allows for calibration of the
AC source measurement system.
T C The OUTPUT CAL menu allows for calibration of the AC source
output.
Following the Menu overview pages is a detailed description of each menu and sub menu.
MENTS
TS
WAVEFORMS
MEAS.
ONS
access t commo ed
etup such as for the G nd RS23 also
enu provides contro AC
(M X45-3Pi model
OUTPU AL
82 MX Series
