Canon J1 - Page 24

M102 M101
M105
M107
M108
SL104 SL101 SL102 SL103
M103
M104
M111
Second tray shift motor drive signal
First tray shift motor drive signal
1st eject roller separation solenoid drive signal DELIV-ROL-SL Inlet roller separation solenoid drive signal INLET-ROL-SL Buffer roller separation solenoid drive signal BUFF-ROL-SL Buffer rear end holding solenoid drive signal BUFF-P-SL
Finisher controller PCB (1/2)
Finisher controller PCB (2/2)
Stack ejection motor drive signal
Rear end assist motor drive signal
Inlet motor drive signal
Stapler drive motor drive signal
Stapler motor drive signal
Aligning plate front/rear
motor drive signal
M109
M110
Gear change motor drive signal
F-2-7
Delivery path paper
detection sensor
TIMING
Inlet paper detection sensor
INLET
Second tray paper detection sensor
TRY2-P
First tray paper detection sensor
TRY1-P
Finisher controller PCB
F-2-8
