Canon J1 - List of Clutches; Other

4
4
4-13
4-13
Parts Replacement and Cleaning Procedure > List of Parts > Other
Parts Replacement and Cleaning Procedure > List of Parts > Other
List of Clutches
CL101
CL102
No. Name Part No Refer to
CL101 Shutter clutch -
-
CL102 Stack ejection lower roller clutch -
-
F-4-16
T-4-16
Other
[1]
[2]
[3]
No. Name Part No Refer to
[1] Paper Folding Roller - (Refer to page 4-37)
[2] No.1 Flapper - (Refer to page 4-39)
[3] No.2 Flapper -
F-4-17
T-4-17
