Parts Replacement and Cleaning Procedure > List of Parts > List of Solenoid > Saddle Finisher Unit
Parts Replacement and Cleaning Procedure > List of Parts > List of Solenoid > Saddle Finisher Unit
List of Solenoid
■
Staple Finisher Unit
SL101
SL102
SL103
SL104
No. Name Part No Refer to
SL101 Feed roller separation solenoid - -
SL102 Buffer roller separation solenoid - -
SL103 1st delivery roller separation solenoid - -
SL104 Buffer rear end holding solenoid - -
F-4-10
T-4-10
■
Saddle Finisher Unit
SL1
SL2
SL5
SL4
No. Name Part No Refer to
SL1 No.1 paper deecting solenoid - -
SL2 No.2 paper deecting solenoid - -
SL4 Feed plate contact solenoid - -
SL5 Saddle inlet solenoid - -
F-4-11
T-4-11
