Technology > Staple Operation > Stapler Unit > Shifting the Stapler Unit
Technology > Staple Operation > Stapler Unit > Shifting the Stapler Unit
●
Rear 1-Point Stapling
The position is the same as the stapling position.
Rear aligning plate
Front aligning plate
Stapling position/
Wait position
Feeding direction
Stopper
F-2-71
●
2-Point Stapling
The stapler waits at the paper front end side staple position. The stapling sequence is rst
near side and then far side.
Rear aligning plate
Front aligning plate
Stopper
Feeding direction
Stopper
Stapling position
Stapling position/
Wait position
Stopper
F-2-72
