1.3.28 Evaporator
Evaporator section options include a semi--hermetic
thermal expansion valve, ahermetic thermalexpansion
valve and two sizes of heat exchangers. The unit may
have 4 or 6 heaters.
1.3.29 Evaporator Fan Operation
Units are equipped with Normal Evaporator Fan
Operation, opening of an evaporator fan internal
protector will shut down the unit.
1.3.30 Labels
Operating Instruction and Function Code listing labels
will differ depending on the options installed. For
example, additional operating instructions are required
to describe start--up of a unit equipped with an
autotransformer. Where the labels are available with
additional languages, they are listed in the parts list.
1.3.31 Plate Set
Each unit is equipped with a tethered set of wiring
schematicand wiringdiagram plates. Theplatesetsare
ordered usinga seven digit base part numberand a two
digit dash number . See the Identification Matrix
manual. T-300.
1.3.32 Controller
T wo different controllers are available:
1. Remanufactured -- Controller is the equivalent of a
new OEM controller and is supplied with a 12 month
warranty.
2. Repaired -- Controller has had previous faults
repaired and upgraded with the latest software.
Note: Repaired controllers are NOT to be used for
warranty repairs only full OEM Remanufactured
controllers are to be used.
Controllers will be factory equipped with the latest
version of operational software, but will NOT be
configured for a specific model number and will need to
be configured, at the time of installation or sale.
The following Part numbers cover ALL previous
MicroLink 2 and 2i controllers:
Part Number
Reman-
ufactured
Repaired
Description
o
e
Usage
12--55002 12--56002
ML2I Recip.
(SWR51XX)
69NT40--511
The identification label on each controller will have the
part number as shown above followed by a dash and
then a blank space to allow the final dash number to be
added at the time of sale.
Once a unit has been configured, the last digits of the
part number can be found in the T--300 Unit Matrix. It is
importantwhen installingacontrollerthatthisfinalpiece
of the part number is added.
Example -- If a repaired controller is required for a
69NT40--511--343, PID NT0809:
Use the ML2I reciprocating compressor base controller
12--56002. The dash number from the T--300 Unit
Matrix (Controller Column) is 90.
The full part number for the necessary controller is
12--56002--90.
1.3.33 Condenser Grille
T wo styles of condenser grilles are available, direct
bolted grilles and hinged grilles.
