7-MAINTENANCE

1.Aftertheenginehascooledandthetemperatureofthe

coolanthasreachedasafelevel,removethedeaera-

tioncap.

RAIL13DOZ1690AA1

2.Thecoolantdrainislocatedbeneaththemachineunder

thefrontpanel.

RAPH12DOZ0095AA2

NOTE:Ifthemachineissoequippedandthespecialdrainingequipmentisavailable,usetheenginecoolantenvi-

ronmentaldrain.

3.Removetheboltsfromtheaccesspanel,andremove

thepanel.

NOTE:Panelisheavy,usecareduringremoval.

4.Placeasuitablecontainerofthepropercapacityunder

thedrain.Openthedraincap,anddrainthecoolant

fromthesystem.

5.Securethedraincapafterallthecoolantisdrained.

6.Useasystemcleaningproducttocleanandushthe

system.Contactyourauthorizeddealerforsystem

cleaningproducts.

7.Followthecleaningproductinstructions.Afterthesys-

temhasbeencleanedandushed,closeandsecure

thedrainvalve.

RAPH12DOZ0097AA3

7-77
