The possible parameter combinations based on the welding process chosen, are as follows:
WELDING
PROCESS
WELDING MODE
PULSED MODE TYPE OF AC WAVE
SLOW PULSE
OFF PULSE
SQUARE
MIX
TRIANGULAR
SINUSOIDAL
DEFAULT ADVANCE
TIG AC
2T 2T ADVANCE (*) X X X X X X
4T X X X X X X
4T AUTO
4T AUTO
ADVANCE (*)
X X X X X X
CYCLE X X X X X X
SPOT X X X X
WELDING
PROCESS
TYPE OF
IGNITION
WELDING MODE
PULSED MODE
OFF PULSE
SYN PULSE
FAST PULSE
ULTRA FAST
PULSE
SLOW PULSE
DEFAULT ADVANCE
TIG DC
HF
2T 2T ADVANCE (*) X X X X X
4T X X X X X
4T AUTO
4T AUTO
ADVANCE (*)
X X X X X
HF
PERFECT
POINT
CYCLE X X X X X
SPOT
COLD TACK
WELDING
PROCESS
TYPE OF
IGNITION
WELDING MODE
PULSED MODE
OFF PULSE
SYN PULSE
FAST PULSE
ULTRA FAST
PULSE
SLOW PULSE
DEFAULT ADVANCE
TIG DC LIFT TIG
2T 2T ADVANCE (*) X X X X X
4T X X X X X
4T AUTO
4T AUTO
ADVANCE (*)
X X X X X
CYCLE X X X X X
SPOT
TIG VALVE TORCH
