Cedar Summit F25720 - Attach Telescope

Step 48: Attach Telescope
A: On the top corner of the Narrow Front Panel, attach Telescope Base on an angle with 2 (S20) #8 x 1-3/8”
Wood Screws. (g. 48.1 and 48.2)
A
A
Fig. 48.1
Fig. 48.2
S20
Hardware Other Parts
2 x #8 x 1-3/8” Wood Screw 1 x Telescope w/ Mount
S20
Narrow
Front
Panel
Telescope
Telescope
Base
