Cedar Summit F25720 - Attach MOD Pane Gable

4 x #8 x 7/8” Truss Screw
A: On one side of the Large Roof Assembly attach 1 MOD 3 Pane Gable to the inside of the (350) Roof
Supports with 4 (S0) #8 x 7/8” Truss Screws. (g. 37.1 and 37.2)
Step 37: Attach MOD Pane Gable
Hardware
S0
MOD 3 Pane
Gable
MOD 3 Pane
Gable
Tight
Tight
Large Roof
Assembly
350
350
350 350
Fig. 37.1
Fig. 37.2
S0
Other Parts
1 x MOD 3 Pane Gable
83 europecustomerservice@kidkraft.com
