Cedar Summit F25720 - Swing Top Assembly

A: Attach (400) Swing Top to 2 (401) Swing Side Uprights with 2 (H3) 1/4 x 2-1/2” Hex Bolts (with lock washer,
at washer and t-nut). (g. 40.1)
Step 40: Swing Top Assembly
Wood Parts
1 x Swing Top 1-1/4 x 3 x 46-3/4”
2 x Swing Side Upright 1-1/4 x 2-1/2 x 16-1/2”
400
Hardware
2 x 1/4 x 2-1/2” Hex Bolt
 (1/4”lockwasher,1/4”atwasher,1/4”t-nut)
401
H3
400
1/4” Flat
Washer
1/4” Lock
Washer
1/4”
T-Nut
H3
401
401
Fig. 40.1
