Cedar Summit F25720 - Attach Ground Stake to TNR Upright

1 x Rebar Ground Stake
Step 34: Attach Ground Stake to TNR Upright
Hardware
1 x #12 x 2” Pan Screw
S7
Other Parts
Fig. 34.1
Rebar
Ground
Stake
Warning! To prevent tipping and avoid potential
injury, stakes must be driven 13” into ground.
Digging or driving stakes can be dangerous if you
donotcheckrstforunder-groundwiring,cables
or gas lines.
A: In the spot shown in g. 34.1 drive 1 Rebar Ground Stake 13” into the ground against the (320) TNR
Ground Brace. Be careful not to hit the washer while hammering stake into the ground as this could cause the
washer to break off.
B: Attach the ground stake to (320) TNR Ground Brace just below the bolt head using 1 (S7) #12 x 2” Pan
Screw as shown in g. 34.1.
C: After driving stakes into the ground, check for sharp edges caused by the impact of the hammer. Smooth
any sharp edges from impact area and touch up with outdoor paint.
320
13” In Ground
S7
79 europecustomerservice@kidkraft.com
