Cedar Summit F25720 - Attach Utensil Shelves

Step 50: Attach Utensil Shelves
Part 1
Hardware Other Parts
2 x #8 x 7/8” Truss Screw 1 x Utensil Shelf
1 x Sign
S0
A: From outside the assembly in the top of the opening of (051) Front Wall Panel, 1” in from the panel, attach 1
Utensil Shelf with 2 (S0) #8 x 7/8” Truss Screws as shown in g. 50.1 and 50.2.
B: Attach Sign to the Utensil Shelf. (g. 50.3)
Fig. 50.1
Fig. 50.2
Fig. 50.3
051
S0
Utensil
Shelf
Utensil
Shelf
Sign
1”
