Cedar Summit F25720 - Attach Wall Supports

Step 41: Attach Wall Supports
A: Tight to the oor boards and tight in each corner of the (050) SW Wall Panel attach 2 (410) Wall Supports to
(050) SW Wall Panel with 3 (S3) #8 x 2-1/2” Wood Screws per support. (g. 41.1)
Fig. 41.1
Wood Parts
2 x Wall Support 1-1/2 x 1-1/2 x 55-1/2”
410
Hardware
6 x #8 x 2-1/2” Wood Screw
S3
Floor
Boards
050
410
410
S3
S3
Tight
