Cedar Summit F25720 - Crowsnest Floor Assembly

A: Lay down (230) Crowsnest Gap Board ush to front of (210) Crowsnest Front and (231) Crowsnest Floor
ush to back of (202) Crowsnest Back. In between the gap and oor boards place another (231) Crowsnest
Floor. (g. 23.1)
B: Attach the (231) Crowsnest Floor Boards with 8 (S20) #8 x 1-3/8” Wood Screws per board and the (230)
Crowsnest Gap Board with 6 (S20) #8 x 1-3/8” Wood Screws. (g. 23.1)
Step 23: Crowsnest Floor Assembly
Hardware
1 x Crowsnest Gap Board 1 x 6 x 29-3/8”
2 x Crowsnest Floor 1 x 6 x 29-3/8”
230
Wood Parts
231
22 x #8 x 1-3/8” Wood Screw
S20
Flush
Fig. 23.1
211
211
x 8 per
oor board
S20
231
230
x 6
S20
210
