Cedar Summit F25720 - Attach Slides to Fort

A
A
Step 51: Attach Slides to Fort
Hardware Other Parts
4 x #12 x 2” Pan Screw 1 x Double Ride Maze
N Wave Slide
S7
Note: Pre-drill all holes using a 1/8” drill bit before installing the pan screws.
A: Place Slide centred in the opening of the (051) Front Wall Panel. (g. 51.1)
B: Attach slide to fort using 4 (S7) #12 x 2” Pan Screws. (g. 51.2)
Fig. 51.1
Fig. 51.2
Slide
051
S7
