Cedar Summit F25720 - Attach Swing Top Assembly

Step 42: Attach Swing Top Assembly
A: Tight to the top of (050) SW Wall Panel and ush to the outside of each (410) Wall Support place Swing Top
Assembly then attach (410) Wall Supports to (401) Swing Side Uprights with 2 (S3) #8 x 2-1/2” Wood Screws per
support. (g. 42.1)
Hardware
4 x #8 x 2-1/2” Wood Screw
Fig. 42.1
S3
Swing Top Assembly
S3
S3
Flush
Flush
410
410
401
050
