Step 24: Crowsnest Wall Assembly
Part 1
A: Place 1 (240) Crowsnest Spacer in front of each (211) Upright Crowsnest so they are ush with the (210)
Crowsnest Front and the (220) Crowsnest Bottoms. Attach using 3 (S11) #8 x 2” Wood Screws per (211) Upright
Crownest and 1 (S11) #8 x 2” Wood Screw per (220) Crowsnest Bottom as shown in g. 24.1.
Hardware
8 x #8 x 2” Wood Screw
2 x Crowsnest Spacer 1-1/4 x 2 x 27-1/2”
240
Wood Parts
S11
211
211
240
Flush
S11
S11
S11
x 3 per board
Fig. 24.1
220
220
