Cedar Summit F25720 - Page 44

Fig. 13.4
Hardware
Fig. 13.5
Inside View
Step 13: Front Wall Assembly
Part 2
C: From the inside of the assembly attach (131) Table Top to slats in (051) Front Wall Panel with 2 Flat Brackets
using 3 (S0) #8 x 7/8” Truss Screws per bracket. (g. 13.4 and 13.5)
6 x #8 x 7/8” Truss Screw
S0
Other Parts
2 x Flat Bracket
051
S0
Flat Panel
Bracket
x 3 per
bracket
Tight
051
