Cedar Summit F25720 - Page 97

Hardware
Fig. 46.4
Fig. 46.5
Fig. 46.6
Fig. 46.7
4 x #12 x 1” Pan Screw
Step 46: Canopy Assembly
Part 2
B: From inside the assembly attach the top two canopy rods to the roof peak using 1 (S6) #12 x1” Pan Screw
per rod. (g. 46.5 and 46.7)
C: Place the bent ends of the left and right rods onto each end of the (441) Porch Top and attach using 1 (S6)
#12 x 1” Pan Screw per rod. (46.6 and 46.7)
S6
canopy hidden for clarity
#12 x1" PS
A
B
C
canopy hidden for clarity
#12 x1" PS
A
B
C
canopy hidden for clarity
#12 x1" PS
A
B
C
canopy hidden for clarity
#12 x1" PS
A
B
C
Canopy removed for clarity
441
Roof peak
S6
S6
